Ask Hytrol: How to Connect the E24™ Global Speed Controller

Ask Hytrol is our monthly video series focused on specific topics to help you maintain your conveyor system and learn about new technology. In this video, you will learn how to connect the E24™ Global Speed Controller.

Ask Hytrol is our monthly video series focused on specific topics to help you maintain your conveyor system and learn about new technology. In this video, you will learn how to connect the E24™ Global Speed Controller.



Begin by turning off the power supply. Then, connect the E24™ Global Speed Controller cable to the power supply. Next, connect the other cable to the first wiring harness on the conveyor. Finally, connect the brown wire from the wiring harness to the third terminal of the E24™ control card on all of the cards that need to communicate with the Global Speed Controller.

Now, you may turn on the power supply and adjust the speed of the conveyor accordingly.E24™Logo

Please note that turning the Global Speed Controller off will cause the conveyor to run at the preset speed.

For more conveyor maintenance tips and information, please contact your Hytrol solutions provider.
